- RS422
- T/R+, T/R- , R+, R- , Ground (Isolation 2500VDC)
- RS485
- Data A+ , Data B- , Ground (Isolation 2500VDC)
- Connector
- Removable
- Date Rate
- RS422 - 115.2 kbps, RS485 - 115.2 kbps
- Source
- USB port
- Input Voltage
- 5 VDC
- Consumption
- 1 W (low power device - draws less than 200mA)
- Driver
- FTDI
- Operating System
- Windows , Linux and Android
- Dimensions (mm)
- 83.0(L) X 54.0(W) X 26.0(H)
- Enclosure
- Aluminium HE30
- Weight
- 100g
- Standard
- 2.0 (backward compatible)
- Data Rate
- 12 Mbps GT-4220-FLP GT-2500-FLP GT-2500-WP POWER METER WGD2MSP
- Operating Temperature
- 0 °C to + 70 °C
- Storage Temperature
- -40 °C to + 85 °C
- Operating Humidity
- 0 to 95% (non-condensing) RS422/RS485 RS422/RS485
